Description

TECHNICAL DATA

Valve Standard:

BS EN593/BS5155

Nominal diameter:

2″-120″/DN50–DN3000

Working pressure:
10Bar/16Bar

Face-to-face:

ISO 5752 Series 13

EN 558 Series 13

BS 5155 Series 2

Flange accommodation:

ANSI B16.1 Class125/150

AWWA C207

MSS SP44 Class150

DIN 2501 PN6/10/16
EN1092-2 PN6/10/16
BS10 Table D/E

JIS B2220 5K/10K/16K

AS4087 PN14/16

Tightness check:

API 598

ISO 5208,

EN12226-2

NOTE: Pinned design and Pinless Design are both available.
